Balluff BVS HS-P Series User Manual

254
4
References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.4.3 Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-
0xFF), used to identify a barcode (symbology) type. It can be appended previous to or following
the transmitted barcode data depending upon how this option is enabled. This feature provides
options for configuring custom Label IDs as a pre-loaded set (see
"Label ID: Pre-loaded Sets"
below) or individually per symbology (see "Label ID: Set Individually Per Symbology" on
page 257). If you wish to program the reader to always include an industry standard label identifier
for ALL symbology types, see "Global AIM ID" on page 59.
Label ID: Pre-
loaded Sets
The reader supports two pre-loaded sets of Label IDs. Label ID Pre-loaded Sets shows the USA
and the EU sets.
Label ID Pre-
loaded Sets
CAUTION
When changing from one Label ID set to another, all other reader configura-
tion settings, including the host interface type, will be erased and set to the
standard factory defaults. Any custom configuration or custom defaults will
be lost.
Symbology
USA Label ID set EU Label ID set
Default
Character
Default
ASCII
Default
Character
Default
ASCII
ABC CODABAR S 530000 S 530000
ANKER PLESSEY o 6F0000 o 6F0000
AZTEC Az 417A00 ! 210000
CHINA SENSIBLE CODE $S 245300 $S 245300
CODABAR % 250000 R 520000
CODE11 CE 434500 b 620000
CODE128 # 230000 T 540000
CODE32 A 410000 X 580000
CODE39 * 2A0000 V 560000
CODE39 CIP Y 590000 Y 590000
CODE39 DANISH PPT $Y 245900 $Y 245900
CODE39 LAPOSTE $a 246100 $a 246100
CODE39 PZN $Z 245A00 $Z 245A00
CODE93 & 260000 U 550000
DATABAR 14 R4 523400 u 750000
DATABAR 14 COMPOSITE R4 523400 c 523400
DATABAR EXPANDED RX 525800 t 740000
DATABAR EXPANDED COMPOSITE RX 525800 d 525800
DATABAR LIMITED RL 524C00 v 760000
DATABAR LIMITED COMPOSITE RL 524C00 i 524C00
