Balluff BVS HS-P Series User Manual

263
www.balluff.com
4
References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.6.3 Reading Active
Time
This setting specifies the amount of time that the reader stays in scan ON state once the state is
entered. The range for this setting is from 1 to 255 seconds in 1-second increments.
Follow these instructions to set this feature:
1 Determine the desired setting.
2 Pad the result with leading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 =
020, etc.
3 Go to page 80 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT READING ACTIVE TIME SETTING.
5 Scan the appropriate three digits from the keypad in Appendix D: Keypad, that represent the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Reading Active Time Setting Examples for some exam-
ples of how to set this feature.
Reading Active
Time Setting
Examples
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting 1 Second
90 Sec.
(1.5 min.)
180 Sec.
(3 min.)
255 Seconds
(4.25 min.)
2 Pad leading zero(es) 001 090 180 255
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT READING ACTIVE TIME SETTING
5
Scan Three
Characters From
Appendix D: Keypad
‘0’, ‘0’ and
‘1’
‘0’, ‘9’ and
‘0’
‘1’, ‘8’ and
‘0’
‘2’, ‘5’ and ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
