62
3
Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
3.6.3 Label ID A Label ID is a customizable code of up to three ASCII characters (convert to Hex using the ASCII
Chart on the inside back cover of this manual), used to identify a barcode symbology type. It can
be appended previous to or following the transmitted barcode data depending upon how this
option is enabled. This feature provides options for configuring custom Label IDs or individually
per symbology (see
"Individually Set Label ID" on page 62). If you wish to program the reader to
always include an industry standard label identifier for ALL symbology types, see the previous fea-
ture "Global AIM ID" on page 59.
See Label ID, starting on page 254 of “References” for more information on setting this feature.
Label ID: Pre-
Loaded Sets
The reader supports two pre-loaded sets of Label IDs. See Label ID: Pre-loaded Sets, starting on
page 254 for details on the USA set and EU set.
Individually Set
Label ID
This feature configures a Label ID individually for a single symbology. To set, first define whether
you want it as a prefix or suffix by reading a label below. Then turn to
Label ID Symbology Selec-
tion − 1D Symbologies, starting on page 63 to select the symbology you want to set, followed by
up to 3 characters from the ASCII Chart at the back of this manual. See Label ID: Set Individually
Per Symbology, starting on page 257 for detailed instructions on setting this feature.
CAUTION
When changing from one Label ID set to another, all other reader con-
figuration settings, including the host interface type, will be erased
and set to the standard factory defaults. Any custom configuration or
custom defaults will be lost.
Label ID Pre-loaded Set = USA Set
Label ID Pre-loaded Set = EU Set
AE(CR)
Ae(CR)
DEFAULT
