2. Start the TEACH mode.
Method Action Result
Push Button
Press and hold TEACH for longer than 2 seconds.
and
flash alternately
on the display. The DYN, FGS, and BGS
indicators flash.
Remote Input
No action required. N/A
3. Teach the sensor.
Method Action Result
Push Button
Press TEACH to teach the target. The sensor is taught the first target.
, , and the current
distance measurement flash alternately
on the display. The DYN, FGS, and BGS
indicators flash.
Remote Input
Single-pulse the remote input.
4. Present the target.
Method Action Result
Push Button
Present the second target. The sensor-to-target distance must be within
the sensor's range.
, , and the distance
measurement flash alternately on the
display. The DYN, FGS, and BGS
indicators flash.
Remote Input
5. Teach the sensor.
Method Action Result
Push Button
Press TEACH to teach the target.
The new switch point flashes rapidly
and the sensor returns to Run mode.
Remote Input
Single-pulse the remote input.
Table 3: Expected TEACH Behavior for Two-Point Static Background Suppression
See Figure 23 on page 34 for the minimum object separation.
Condition TEACH Result Display
Two valid distances that are greater
than or equal to the horizontal
minimum object separation
Sets a switch point between the two taught
distances.
The switch point distance flashes on
the display.
Two valid distances that are less than
the horizontal minimum object
separation
Sets a switch point in front of the furthest taught
distance by the horizontal minimum object
separation.
and the switch point distance
flash
alternately on the display.
One valid distance with one invalid
TEACH point
Sets a switch point between the one taught
distance and the maximum range.
and the switch point distance
flash
alternately on the display.
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
20 www.bannerengineering.com - Tel: 763.544.3164
