Banner Q4X User Manual

Condition TEACH Result Display
One valid TEACH point with both
switch points in range (with offset, if
applicable)
Sets a window (two switch points) centered
around the taught distance. The ± window size is
the vertical minimum object separation. The two
switch points always stay within the specified
sensing range.
The ± window size flashes on the
display.
One invalid TEACH Point
Sets a window (two switch points) centered
around the following location:
Model Window Center
Point
100 mm threaded barrel models 80
300 mm threaded barrel models 250
600 mm threaded barrel models 500
110 mm flush mount models 90
310 mm flush mount models 260
610 mm flush mount models 510
The window size is:
Model Window Size
100 mm threaded barrel and 110
mm flush mount models
±12.5 mm
300 mm threaded barrel and 310
mm flush mount models
± 25 mm
600 mm threaded barrel and 610
mm flush mount models
± 25 mm
and the window center point
distance
flash alternately on the
display.
One valid TEACH point with one
switch point within range and one
switch point out of range (with offset,
if applicable)
Sets a window (two switch points) that is
centered at the TEACH point (after offset, if
applicable) with one switch point at the maximum
range.
and the ± window size
flash
alternately on the display.
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
24 www.bannerengineering.com - Tel: 763.544.3164

Banner Q4X Specifications

General

Sensing Mode	Diffuse
Input Voltage	10 V DC to 30 V DC
Output	NPN or PNP
Housing Material	Stainless steel
IP Rating	IP67
Connection Type	M12
