Abbreviation Description
Lock/locked
Laser off
Master
Near zero reference location—the front of the sensor is 0 and the measurement increase as the target
moves further away from the sensor
Object
,
Off delay timer (Channel 1, Channel 2)
Off
,
Offset (Channel 1, Channel 2)
An applied offset resulted in an invalid switch point
On
,
On delay timer (Channel 1, Channel 2)
,
Output (Channel 1, Channel 2)
Pulse frequency modulation
Reset to factory defaults
Save
Set or Input wire = remote teach function
Shift the Zero Reference Location after a TEACH
Slave
Response speed
Standard excess gain mode
Start
Stop
,
TEACH process selection (Channel 1, Channel 2)
Totalizer
,
Total counts
Unlock/unlocked
Saturated signal (too much light)
,
Window size (Channel 1, Channel 2)
Yes
Zero—select the zero reference location
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
www.bannerengineering.com - Tel: 763.544.3164 39
