Chapter 2 Disassembly Process
2-35
CLM W6_CLM HD6 Jan 31, 2012
6. Separate air duct, blower and rubber
.
7. Unscrew 4 screws (red circle) to
remove lamp housing.
8. Unscrew 2 screws (yellow circle) to
disassemble lamp housing module.
45
47
