Chapter 2 Disassembly Process
2-36
CLM W6_CLM HD6 Jan 31, 2012
9. Unscrew 4 screws (yellow circle) to
disassemble lamp housing.
10. Unscrew 4 screws (red circle) to
disassemble 2 lamp cables.
