Chapter 2 Disassembly Process
2-43
CLM W6_CLM HD6 Jan 31, 2012
2. Unscrew 4 screws (yellow circle) to
disassemble fan module.
3. Unscrew 1 screw (red circle) to
disassemble fan module.
