CLM W6_CLM HD6 Jan 31, 2012
Chapter 1 Introduction
No Item Description
� Projection lens
• Standard lens (WT91) ≈ 1.45-1.94 (WUXGA),
1.52-2.03 (WXGA), Zoom Ratio : 1.33X
• Fixed Lens (WT96) ≈ 0.77 (WUXGA), 0.81 (WXGA)
• Wide Zoom (WT93) ≈ 1.20-1.45 (WUXGA),
1.27-1.52 (WXGA), Zoom Ratio : 1.2X
• Standard Zoom (WT95) ≈ 2.0-3.80 (WUXGA),
2.03-3.85 (WXGA), Zoom Ratio : 1.9X
• Long Zoom (WT94) ≈ 3.67-6.98 (WUXGA),
3.85-7.32 (WXGA), Zoom Ratio : 1.9X
8 Lamp life
• Total hours needed to decrease the lumens of the test
sample’s median lamp to 50% of original value:
1500 (Normal), 2000(ECO)
9 Terminal
• Computer In x2, VESA (HD15) Blue, Female
• Monitor out x1, VESA (HD15) black, Female
• HDMI, version 1.3v x2
• CVBS In (Composite Video) RCA connector (Y), Female x1
• SVHS In (S-Video), 4-pin mini DIN, Female x1
• Provides S-Video input x1
• BNC RGBHV, BNC 75ohm Females x1 sets
• DC output. 3.5mm jack, Female x1,
Volts: 12v Amps: 250ma Max
• 9-pin RS232 male (d-sub) x1
• RJ45
10 Input single
• Hsync Frequency: 15 ~ 91.1 kHz
• Vsync Frequency: 43 ~ 85 Hz
• Video Signal RGB (PC)
Analog RGB: 0.7Vp-p, 75 ohm
Analog RGB: 1Vp-p, 75 ohm, Sync. Signal
Separate TTL H,V Sync.
Composite TTL Sync.
• Video
Composite video: 1Vp-p,�5 ohm
S-video Luminance: 0.714Vp-p,75 ohm
S-video Chrominance: 0.286Vp-p,75 ohm
