1-3
CLM W6_CLM HD6 Jan 31, 2012
Chapter 1 Introduction
No Item Description
11 DMD chip
• DMD TYPE-A 1280x800 PIXEL 0.65” WXGA-800 2xLVDS
“TI” (for CLM W6)
• DMD TYPE-A 1080P 0.65” 2xLVDS (for CLM HD6)
12 Native resolution
• 1280x800 WXGA (for CLM W6)
• 1920x1080 1080P (for CLM HD6)
13 Video compatibility
• Standards :
NTSC, NTSC4.43
PAL/PAL-M/PAL-N/SECAM
SDTV compatible (480i/p, 5�6i/p)
HDTV compatible (�20p, 1080i, 1080p)
14 Computer compatibility
Apple® Macintosh®, iMac®, and VESA Standards:
WUXGA, UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA
15 Color Wheel
• Standard:
5-segment: R:80°/Y:30°/G:84°/W:90°/B:76°
• Optional:
6-segment: R:100°/C:23°/B:72°/G:90°/M:30°/Y:45°
16 Lamp • OSRAM 2xP-VIP 330W/1.0 E20.9 x2
1� System controller
• CLM HD6:
DUAL TI DDP 3021
• CLM W6
TI DDP 3020F
18 Cooling system
• - Advanced Air Flow
- Eleven fans with system acoustic noise level
- Temperature control circuits with adaptive fan rotational
speeds
- Maximum touch temperature meets UL60950-1
19 Temperature • Operating: 5°C -- 35°C
To Next Page
