14. Maintenance procedures

4

3

3

Image 14-4

6. Install the dust ﬁlter assembly bac k a t the front side of the projector. Use a 7mm ﬂat screwdriver to fasten the captive s crew.

The dust ﬁlter is cleanable. See cleaning procedure for correct cleaning and d rying instructions.

R5906847 DP2K SLP SERIES 02/06/2017 125
