11. Convergence
11.2 Preparing for convergence ad justment
Necessary tools
•7mmflat screwdriver.
• 3mm Allen wrench.
How to s et up the projector for convergence adjustment?
1. Remove the top cover from of the projector.
2. Remove the left side cover from of the projector.
3. Remove the top cover plate of the Light Processor compa rtment.
4. Remove the left cover plate of the Light Pr ocessor compartment.
5. Place the fan on top of the Light Proc essor in the upper position as illustrated. D o this by engaging the two lower slots (reference
2 image 11-3) into the upper m ounting pins as illustrated. The two upper slots (reference 3 image 11-3) remain free.
3
2
Image 11-3
6. Switch on the projector, ignite the lamp and open the dowser.
7. Select the convergence t est pattern, which is illustrated below (image 11-4). Us e the comm unicator to activate the convergenc e
test pattern.
Note: The conv ergence test pattern can NOT be activated via the PATTERN button on the Local Keypad.
4
1
2
5
3
6
Image 11-4
108 R5906847 DP2K SLP SERIES 02/06/2017
