Barco DP2K SLP Series

15. Removal and installation of the projector covers
15.2 Removal of the rear cover
WARNING: Switch off the projector prior to start with this procedure, unless otherwise specified in the pro-
cedure.
Necessary tools
Flat screwdriver 7 mm
How to remove the rear cover?
1. Loosen the four captive s crews (reference 1 image 15-2) of the rear c over using a 7 mm flat screwdriver.
2. Remove the rear cover from the projector.
1
Image 15-2
R5906847 DP2K SLP SERIES 02/06/2017 133
