7. ICMP

7.3 ICMP communication ports

Location of the communication ports

1 2 3 4 5 6 7

Image 7-7

ICMP (with HDMI 2.0).

Functionality

AUDIO-AES 1-8 (9-16)

ICMP outputs sixteen audio signals e quitably distributed over these two RJ45 connectors, which can be conﬁgured

independently. The mapping of audio channels (content) on each audio output (AES outputs of the ICMP ) is performed by

conﬁguring the ICMP via the Com munic ator software. P lease refer to the Communicator user guide for further information.

GPO 1-4 (5-8)

These RJ45 c onnectors can be use d to send trigger signals to other d evices. The mapping of use r Cues (output Cues) on

each G eneral Purpose Output (GPO) is conﬁgured via the Communicator software. Please refer to the Communica tor

user guide for further information.

GPI 1-4 (5-8)

These RJ45 connectors can be used to receive trigger signals from other devices. The mapping of the G eneral Purpose

Input (G PI) on each input Cues is conﬁ gur ed via the Communicator software. Please refer to the Com mun icator user

guide for further information.

SYNC IN / O UT

Synchronization signal IN and OUT: Reserved for m ultiple-projector projection. Use a 50 O hm coaxial cable to connect

the sync signal from projector to projector.

LAN 1 (2)

The ICMP can be connected to a LAN (local area network) using one of the Ethernet ports. These LAN port are used

for ‘content’ transfer.

NOTE: These ports are optionally used to connect to external content storage sources. Control of the ICMP is done via the

same IP address as the projector.

USB 2.0

The ICMP can be connected to a USB 2.0 Media to load content. T he USB port can be used to load content (DCP) or

keys (KDM).

NOTE: It is recommended to use the US B 3.0 ports for faster ingest.

USB 3.0

The ICMP c an be connected to a USB 3.0 M edia t

o load content. The USB port c an be used to load c ontent (DCP), or

keys (KDM), or software u pdate.

NOTE: These por ts are recommended for fast ingest when connected to an appropriate USB 3.0 source.

R5906847 DP2K SLP SERIES 02/06/2017
