15. Removal and installation of the projector covers

15.10 Installation of the t op cover

Necessary tools

Flat screwdriver 7 mm

How to install the top cover?

1. Install the top c over on the projector.

2. Fasten the four captive s crews (reference 1 image 15-14) of the top cover using a 7 mm ﬂat screwdriver.

1

Image 15-14

142 R5906847 DP2K SLP SERIES 02/06/2017
