15. Removal and installation of the projector covers

15.11 Installation of the rear cover

Necessary tools

Flat screwdriver 7 mm

How to install the rear cover?

1. Install the rear cover on the projector.

2. Fasten the four captive screws (reference 1 image 15-15) of the rear cover using a 7 mm ﬂat screwdriver.

Image 15-15

R5906847 DP2K SLP SERIES 02/06/2017 143
