4. Physical installation
90°
Inclined screen
Image 4-4
CAUTION: The DP2K SL P -series may tilt m aximum 20° f orward and maximum 5° backwards. No tilt is allowed
sideways.
The back feet of the projector can be turned out maximum 150 mm. This correspond with a forward tilt of 7°
if the front foot is completely turned in.
Barco offers a pedestal for the DP2K SL P -series p rojector. This universal pedestal allows you to easily tilt the
projectorforwardupto6°.
Use the tilt of the projector feet and the pedestal to get sufficient tilt.
30 R5906847 DP2K SLP SERIES 02/06/2017
