7. ICMP

Card Cage slot location

The Card Cage can be different depend ing the projector type but it always consists of a button m odule and se veral rem ovable units.

The ICMP (reference 1 ) is inserted into the former ICP slot and IMB slot abov e the Barco Cinema Controller ( reference 2).

ICMP location in the Ca rd C age of a S-series projector.

Image 7-5

R5906847 DP2K SLP SERIES 02/06/2017 55
