7. ICMP
Audio formats
• 2 c hannels / LPCM / 16 bits / 32 k Hz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
• 5.1 format / L PCM / 24 bits / 48 kHz
• 7.1 format / L PCM / 20 bits / 48 kHz
Notes:
• DisplayMode = S ingle : is applicable to bo th DisplayPort A, and DisplayPort B input, separately.
• DisplayMode = A+B : inputs DisplayPort A and DisplayP ort B are co mbined to 1 larger im age; in this case the 2 DisplayPort
links need to be genlocked ( = synchronous and in phas e).
• In all cases :
- Color Sp ace - Color Sampling:
o
YCbCr-4:4:4
o
YCbCr-4:2:2
o
RGB - 4:4:4
- Scan Type = progressive.
• Both N vidia and AM D GPU’s will not support color depths of 10 bits/color while in 3D-stereo mode.
• Some G raphical Cards may not permit 10 bits/color at all video timings, because of bandwidth restrictions.
• DisplayPort A and DisplayPort B autom atically detect:
- Active Pixels, and Active Lines
- Vertical Refresh
- 8 bits/color - 10 bits/color
- Frame locked
• All input re solutions are scaled towards the desired resolution specified in the screen presentation file.
• Fractional frame rates = (Hz*1000)/1001
R5906847 DP2K SLP SERIES 02/06/2017
61
