7. ICMP
SMPTE Standard Source Resolution
Frame Rate Display Rate
Scan Type
SMPTE 274M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
23.976
24
25
29.970
30
Segmented frame
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M
1920 x 1080 25
29.970
30
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
Standard HD-SDI (2 × SMP TE 292M) formats
2
SMPTE Standard Source Resolution
Frame Rate Display Rate
Scan Type
SMPTE 292M
SMPTE 428-8
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Progressive
Y C b Cr 4:2:2 10-Bit
SMPTE 292M
SMPTE 428-9
(SMPTE RP211)
1920 x 1080
2048 x 1080
23.976
24
25
29.97
30
47.952
48
50
59.940
60
Segmented frame
Y C b Cr 4:2:2 10-Bit
The standard HD-S DI interfaces support the Y Cb Cr colorspace (both legal and full range) using 4:2:2 c olor subsa mpling.
The Dua l-Link HD-S DI interface c an be used to carry a single 4:4:4 image, having a color depth of 10 or 12 bit per c omponent. Both
RGB (XYZ) and Y Cb Cr color spaces are supported.
SMPTE 424M 3G HD-SDI 2.970 Gb/s SIGNALS
3G HD-SDI (SMPT E 425 ) formats
SMPTE Standard Source Resolution
Frame Rate Display Rate
Scan Type
SMPTE 296M
1280 x 720 23.976
24
25
29.970
30
50
59.940
60
23.976
24
25
29.970
30
50
59.940
60
Progressive
Y C b Cr 4:4:4 10-Bit
RGB (XYZ) 4:4:4 10 -Bit
SMPTE 274M
3
1920 x 1080 50
59.940
60
50
59.940
60
Progressive
Y C b Cr 4:2:2 10-Bit
SMPTE 274M
1920 x 1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
2. mainly used to carry stereoscopic images.
3. only supported in 3G level A mapping, others formats are supported in both level A and level B mapping.
