30 Technical Data
CFPP Process Analyzer CFPP-4.2 03/2016
Control unit
Central control unit industry standard PC
Operating system
Windows XP
Control software PACS
Remote maintenance
(optional)
remote maintenance software via modem, ISDN or
Ethernet
User interfaces
Touchscreen TFT display with touch function, 800 x 600 pixels
Keyboard virtual keyboard, controlled via TFT display with touch
function
Connections
Pipe fittings
Swagelok
6 mm / 12 mm / 18 mm, (
”,
”) on request
Vent / Drain open to atmosphere
Max. high of the drain
connection
200 mm above the floor
Cable inlets M20 / M25
Weight and Dimensions
Weight approx. 400kg (without optional equipment)
Dimensions (B x H x T) approx. 1140 mm x 2030 mm x 710 mm
Required space Right and left hand side approx. 0.5 m free space (supply
air and exit air for Chiller for Liquids)
For option Chiller for Liquids you need free space on the
left and on the right hand side according to specification.
Noise Emission
Emission sound pressure
level
79 dB(A)
Options
Sample conditioning system
Cooling system for the control box
Validation system
* If a vortex cooler is used for the control box, make sure that at the very most drip water can hit
the analyzer in compliance with EN 60529.
Note: The analyzer is subject to continuous improvements, so that technical changes
are possible.
