Installation and Disassembly 51
03/2016 CFPP Process Analyzer CFPP-4.2
7.2 Disassembly
7.2.1 Disconnecting Electrical Connections
The analyzer operates with electrical power.
Dangerous electric current!
If you touch components carrying electric current, the elec
trical power can
cause serious injury or death.
FOR THIS REASON:
- Switch off the power supply and secure it, so that it cannot be
switched on accidentally.
- All work on the electrical system must be carried out by personnel
qualified for electrical installation and explosion protection.
- Do not remove or disable any protective devices.
• Disconnect the analyzer completely from the power supply.
• Secure to prevent the system from being switched on again.
• Open the junction box.
• Disconnect all cable connections and pull them out of the junction box.
• Unscrew the equipotential bonding cable at the frame.
• Close the junction box.
The analyzer is now disconnected from the power supply.
