BARTEC BENKE CFPP-4.2 User Manual

64 Operation
CFPP Process Analyzer CFPP-4.2 03/2016
9.1 Switching on the Analyzer
To switch on the analyzer, proceed as follows:
• Open the shut-off valve in the product feed line, if it is not already open.
• Make sure that pressure and flow rates for product and instrument air are adjusted
correctly (see chapter 8).
• Check the protective devices (see chapter 2.5).
• Switch on the power, using the separator for the power supply (fuse or main switch)
for the analyzer.
• The control box and the measuring cell housing are purged with instrument air (loud
noise).
2
1
Fig. 9.1: Overpressure control display
1 Touchscreen
2 Overpressure control display
• The remaining purge time is displayed by the overpressure control system (2).
