92 Maintenance
CFPP Process Analyzer CFPP-4.2 03/2016
Fig. 10.14: Sample container (without sample)
• The liquid level of the sample should correspond to the level mark on the sample
container.
• If it does not, measure the distance between the liquid level and the level mark and
make a note of it, then adjust the liquid level (see chapter 10.14.2).
• Empty the sample container and clean it.
The measuring cell can now be reassembled and reinstalled.
• Check all O-rings. If there are signs of damage, replace the O-ring.
Fig. 10.15: O-ring sample container
10 O-ring of the sample container
5 Red plastic ring
• Apply a small amount of mounting paste to the O-ring (10) of the sample container.
• To mount the sample container, hold the red plastic ring (5), not the glass body (4).
