Configuring the Camera
BASLER A102
f 4-9
DRAFT
Register Name: Feature Low Inquiry
Offset from Base Address: 0x408
Field Bit Description A102f
Value
A102fc
Value
Zoom
0 Zoom control availability 0 0
Pan 1 Pan control availability 0 0
Tilt 2 Tilt control availability 0 0
Optical Filter 3 Optical filter control availability 0 0
--- 4 ... 15 Reserved --- ---
Capture Size 16 Format 6 capture size availability 0 0
Capture Quality 17 Format 6 capture quality availability 0 0
--- 18 ... 31 Reserved --- ---
Register Name: Optional Function Inquiry
Offset from Base Address: 0x40C
Field Bit Description A102f
Value
A102fc
Value
---
0 Reserved --- ---
PIO 1 Parallel input/output control availability 1 1
SIO 2 Serial input/output control availability 0 0
Strobe Output 3 Strobe output control availability 1 1
--- 4 ... 31 Reserved --- ---
Register Name: Advanced Features Inquiry
Offset from Base Address: 0x480
Field Bit Description
Advanced Feature
Quadlet Offset
0 ... 31 Indicates the quadlet offset from the base address of the initial register
space for the advanced features Control and Status Registers (CSR).
The A102f and A102fc support advanced (vendor unique) features.
