Configuring the Camera
4-10 BASLER A102
f
DRAFT
Register Name: PIO Control CSR Inquiry
Offset from Base Address: 0x484
Field Bit Description
PIO Control
Quadlet Offset
0 ... 31 Indicates the quadlet offset from the base address of the initial register
space for the PIO Control and Status Registers (CSR).
The A102f and A102fc support PIO control.
Register Name: Strobe Output CSR Inquiry
Offset from Base Address: 0x48C
Field Bit Description
Strobe Output
Quadlet Offset
0 ... 31 Indicates the quadlet offset from the base address of the initial register
space for the strobe output Control and Status Registers (CSR).
The A102f and A102fc support strobe output control.
