Configuring the Camera
4-12 BASLER A102
f
DRAFT
Register Name: Shutter Inquiry
Offset from Base Address: 0x51C
Field Bit Description A102f
Value
A102fc
Value
Presence Inq
0 Shutter control feature is present 1 1
Abs Control Inq 1 Shutter can be set with an absolute value 0 0
--- 2 Reserved --- ---
One Push Inq 3 One push auto mode is present 0 0
Read Out Inq 4 The shutter value can be read 1 1
On/Off Inq 5 Shutter control can be switched on/off 0 0
Auto Inq 6 A shutter auto control mode is present 0 0
Manual Inq 7 The shutter value can be set manually 1 1
Min Value 8 ... 19 Minimum value for shutter 1 1
Max Value 20 ... 31 Maximum value for shutter In Format 2, depends on
the format, mode and
frame rate settings.
In Format 7, the maxi-
mum is 4095.
