Configuring the Camera
BASLER A102
f 4-13
DRAFT
Register Name: Gain Inquiry
Offset from Base Address: 0x520
Field Bit Description A102f
Value
A102fc
Value
Presence Inq
0 Gain control feature is present 1 1
Abs Control Inq 1 Gain can be set with an absolute value 0 0
--- 2 Reserved --- ---
One Push Inq 3 One push auto mode is present 0 0
Read Out Inq 4 The gain value can be read 1 1
On/Off Inq 5 Gain control can be switched on/off 0 0
Auto Inq 6 A gain auto control mode is present 0 0
Manual Inq 7 The gain value can be set manually 1 1
Min Value 8 ... 19 Minimum value for gain 192 192
Max Value 20 ... 31 Maximum value for gain When the camera is set for
anything other than Mono
16 output:
max = 1023
When the camera is set for
Mono 16 output:
max = 511
