Configuring the Camera
4-18 BASLER A102
f
DRAFT
Register Name: Memory Save Channel
Offset from Base Address: 0x620
Field Bit Description
Save Channel 0 ... 3 When a 1 is written to the Memory Save register (see page 4-17), the
current settings in the work configuration set (see Section 3.15) will be
saved to the memory channel specified in this register.
The valid values for this register are 1, 2 and 3.
---
4 ... 31 Reserved
Register Name: Current Memory Channel
Offset from Base Address: 0x624
Field Bit Description
Current Channel 0 Writing a value to this field will cause the settings saved in the specified
memory channel to be copied into the work configuration set (see Sec-
tion 3.15). The valid values for writing to this register are 0, 1, 2 and 3.
Reading the value from this register will indicate the last memory chan-
nel that was copied into the work configuration set.
---
1 ... 31 Reserved
Register Name: VMode Error Status
Offset from Base Address: 0x628
Field Bit Description
Status 0 Used only when the camera is set for a standard format (not Format 7).
This field will be updated each time the video format, mode, frame rate
or ISO speed setting is changed. The value in this field indicates
whether the current combination of video format, mode, frame rate and
ISO speed settings is acceptable to the camera.
0 = the combination is OK, image capture can be started
1 = the combination is not OK, image capture can not be started
This field is read only.
---
1 ... 31 Reserved
