Basler A504k User Manual

Configuring the Camera
Basler A500k Series 4-19
PRELIMINARY
4.2.4.13 Area of Interest Feature
Purpose: To activate or deactivate the Area of Interest Stamp and Dynamic Area of Interest or to read
the settings. See Sections
3.9.3 and 3.9.2 for details.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0x99 1 1 -
Response: Cmd-ID R/W-Flag Data Length Data
0x99 0 1 1 Byte
Write Command: Cmd-ID R/W-Flag Data Length Data
0x99 0 1 1 Byte
Response: None
Data Format: Byte 1 An ID that specifies whether AOI Stamp and Dynamic AOI are
acivated or deactivated (see the table below).
ID Setting
0x00 AOI Stamp and Dynamic AOI deacti-
vated (standard mode)
0x40 AOI Stamp deactivated and Dynamic
AOI activated
0x80 AOI Stamp activated and Dynamic AOI
deactivated
0xC0 AOI Stamp and Dynamic AOI activated
