3.10 Test Images
The test image mode is used to check the camera’s basic functionality and its ability to transmit
an image via the video data cable. The test image can be used for service purposes and for failure
diagnostics. In test mode, the image is generated with a software program and the camera’s digital
devices and does not use the optics, CMOS sensor, or ADCs.
You can put the camera in test image mode using either the Camera Configuration Tool Plus (see
Section 4.1) or binary commands (see Section 4.2). You use Test Image command.
There are four test images:
• a gray scale test image
• a color test image (
A504kc and A501kc only)
• a running line test image
• a white screen test image
If the camera is set for an exposure mode that uses an ExSync signal, an ExSync signal is
required to output the test image. If the camera is set for free-run, each cycle of the camera’s
internal sync signal will trigger the output of a test image.
*
When one of the test images is active, the gain, offset and exposure time have no ef-
fect on the image.
