Basler A504k User Manual

Configuring the Camera
Basler A500k Series 4-17
PRELIMINARY
4.2.4.9 Area of Interest Starting Column
4.2.4.10 Area of Interest Width in Columns
Purpose: To set the left starting column for the Area of Interest or to read the current starting column
setting. See Section
3.9 for details.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xA9 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0xA9 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xA9 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of the starting pixel setting
Byte 2 High byte of the starting pixel setting
Data Range:The starting column can range from 0x0000 to 0x04F6. It can only be set in steps of 10.
When you set column
n using this command, the actual starting column will be n + 1. For example, if
you set the starting column to 0 with this command, the actualstarting column =0 +1 =1.
Purpose: To set the width in columns for the Area of Interest or to read the current width setting. See
Section
3.9 for details.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xAB 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0xAB 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xAB 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of the length in pixel setting
Byte 2 High byte of the length in pixel setting
Data Range: The width in columns can range from 0x000A to 0x0500. The width can only
be set in steps of 10.
