2.3 Camera Link Implementation in the A500
A500A500
A500k
The A500k uses a National Semiconductor DS90CR287 as a Camera Link transmitter. For a
Camera Link receiver, we recommend that you use the National Semiconductor DS90CR288, the
National Semiconductor DS90CR288A or an equivalent. Detailed data sheets for these
components are available at the National Semiconductor web site (www.national.com). The data
sheets contain all of the information that you need to implement Camera Link, including
application notes.
The
A500k uses a National Semiconductor DS90LV048A differential line receiver to receive the
RS-644 camera control input signals and the serial communication input signal defined in the
Camera Link specification. A DS90LV047A differential line transmitter is used to transmit the serial
communication output signal defined in the specification. Detailed spec sheets for these devices
are available at the National Semiconductor web site (www.national.com).
The
A504k/kc uses the full configuration of Camera Link with three differential line receivers and
three differential line transmitters. The schematic in Figure 2-5 shows the interface for the
A504k/
kc.
The schematic in Figure 2-6 shows the interface for the A501k/kc and a typical implementation for
the frame grabber interface. The
A501k/kc uses one differential line receiver and one differential
line transmitter.
*
Note that the timing used for sampling the data at the Camera Link receiver in the
frame grabber varies from device to device. On some receivers, TTL data must be
sampled on the rising edge of the receive clock, and on others, it must be sampled
on the falling edge. Also, some devices are available which allow you to select either
rising edge or falling edge sampling. Please consult the data sheet for the receiver
that you are using for specific timing information.
