Basler A504k User Manual

Introduction
Basler A500k Series 1-3
PRELIMINARY
Gain and Offset Programmable via the framegrabber via a serial link
Connectors All versions: 26 pin, 0.5“, mini D ribbon (MDR) plug (data)
one 6 pin, Hirose HR (power)
one 4 pin, Hirose HR (flash control)
A504k/kc: second 26 pin, 0.5“, mini D ribbon (MDR) plug
(data)
one 15 pin, high density sub female (VGA moni-
tor output)
VGA monitor output
640 x 480 pixels at 60 Hz -
Power Requirements 12 VDC ± 10%; max 6 W 12 VDC ± 10%; max 3 W
Housing Size (L x W x H)
including connectors
without lens adapter: 43 x 90 x 90 mm
with F-mount adapter: 87 x 90 x 90 mm
Lens Adapters F-mount
Weight
without lens adapter:
with F-mount adapter:
~
510 g ~
600 g
~ 520 g
~ 610 g
Vibration
tested according to DIN IEC 60068-2-6
3 axes, x,y,z
5-8.5 Hz / 1.5mm
8.5-150 Hz/ 10m/s²
Shock
tested according to DIN IEC 60068-2-27
3 axes, x,y,z
100m/s², 11ms, 3 shocks positive
100m/s², 11ms, 3 shocks negative
Bump
tested according to DIN IEC 60068-2-29
100m/s², 11ms, 100 shocks positive
100m/s², 11ms, 100 shocks negative
Conformity CE, FCC
Specifications
A504k A504kc A501k A501kc
Table 1-2: A500k Performance Specifications

Basler A504k Specifications

General

Brand	Basler
Model	A504k
Category	Security Camera
Language	English
