Basler Camera User Manual

AW00123402000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 7
* Unless otherwise noted, the values given for power consumption are maximum values.
Specification acA2000-165um/umNIR/uc acA2040-90um/umNIR/uc
Sensor Size
(H x V pixels)
um: 2048 x 1088
uc: 2046 x 1086
um: 2048 x 2048
uc: 2046 x 2046
Sensor Type CMOSIS CMV2000-2E5M/2E12M/2E5C
Progressive scan CMOS
Global shutter
CMOSIS CMV4000-2E5M/2E12M/2E5C
Progressive scan CMOS
Global shutter
Optical Size 2/3" 1"
Pixel Edge Length (H x V) 5.5 µm x 5.5 µm
Max. Frame Rate
(at full resolution)
TBD TBD
Mono/Mono (NIR)/Color Mono or mono (NIR) or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Models: Mono 8 Mono 12p
Mono 12
Color Models: Bayer BG 8
Bayer BG 12
Bayer BG 12p
ADC Bit Depth TBD
Synchronization Via external trigger signal, via the USB 3.0 port or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC, compliant with the Universal Serial Bus 3.0 specification, supplied
via the camera’s USB 3.0 port
TBD ~ 3.0 W* @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines
Lens Adapter C-mount, CS-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without lens adapter or connectors)
48.2 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 80 g
Conformity CE, UL (in preparation), FCC, GenICam V. 2.x (including PFNC V. 1.x and SFNC V.
2.x), IP30, RoHS, USB3 Vision, USB-IF (in preparation)
Software Basler pylon 4 Camera Software Suite (version 4.0 or higher)
Available for Windows in 32 and 64 bit versions.
Table 4: General Specifications
