Basler Camera User Manual

Specifications, Requirements, and Precautions AW00123402000
8 Basler ace USB 3.0
* Unless otherwise noted, the values given for power consumption are maximum values.
Specification acA2500-14 um/uc
Sensor Size
(H x V pixels)
um: 2592 x 1944
uc: 2590 x 1942
Sensor Type Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1/2.5"
Pixel Edge Length (H x V) 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
14 fps
Mono/Color Mono or color (color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Model: Mono 8 Mono 12p
Mono 12
Color Model: Mono 8 Bayer GB 12p
Bayer GB 8 YCbCr422_8
Bayer GB 12
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the USB 3.0 port or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
(The maximum value is
indicated for power
consumption).
Nominal +5 VDC, compliant with the Universal Serial Bus 3.0 specification, supplied
via the camera’s USB 3.0 port
~2.2 W* @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines
Lens Adapter C-mount, CS-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without lens adapter or connectors)
48.2 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 80 g
Conformity CE, UL (in preparation), FCC, GenICam V. 2.x (including PFNC V. 1.x and SFNC V.
2.x), IP30, RoHS, USB3 Vision, USB-IF (in preparation)
Software Basler pylon 4 Camera Software Suite (version 4.0 or higher)
Available for Windows in 32 and 64 bit versions.
Table 5: General Specifications
