Basler Camera User Manual

AW00123402000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 9
Specification acA3800-14um/uc acA4600-10uc
Sensor Size
(H x V pixels)
um: 3856 x 2764
uc: 3856 x 2764
uc: 4608 x 3288
Sensor Type Aptina MT9J003
Progressive scan CMOS
Rolling shutter
Aptina MT9F002
Progressive scan CMOS
Rolling shutter
Optical Size 1/2.3"
Pixel Edge Length (H x V) 1.67 µm x 1.67 µm 1.4 µm x 1.4 µm
Max. Frame Rate
(at full resolution)
14 fps 10 fps
Mono/Color Mono or color (color models include a
Bayer pattern RGB filter on the sensor)
Color
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Model: Mono 8
Mono 12
Mono 12p
Color Model: Mono 8
Bayer GB 8
Bayer GB 12
Bayer GB 12p
YCbCr422_8
Color Model: Mono 8
Bayer GB 8
Bayer GB 12
Bayer GB12p
YCbCr422_8
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the USB 3.0 port or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC, compliant with the Universal Serial Bus 3.0 specification, supplied
via the camera’s USB 3.0 port
~3.8 W (typical)* @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, 2 direct-coupled GPIO lines
Lens Adapter C-mount, CS-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without lens adapter or connectors)
48.2 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 80 g
Conformity CE, UL (in preparation), FCC, GenICam V. 2.x (including PFNC V. 1.x and SFNC V.
2.x), IP30, RoHS, USB3 Vision, USB-IF (in preparation)
Software Basler pylon 4 Camera Software Suite (version 4.0 or higher)
Available for Windows in 32 and 64 bit versions.
Table 6: General Specifications
