22. Press the Raise/Scroll
pushbutton. The screen at right is displayed.
Connect a resistance of 175 ohms across the oil pressure sender input
(P13 and P19). Press the Lower/Scroll pushbutton.
23. Press the Raise/Scroll
pushbutton. The screen at right is displayed.
Connect a resistance of 200 ohms across the oil pressure sender input
(P13 and P19). Press the Lower/Scroll pushbutton.
24. Press the Raise/Scroll
pushbutton. The screen at right is displayed.
Connect a resistance of 225 ohms across the oil pressure sender input
(P13 and P19). Press the Lower/Scroll pushbutton.
After step 24 is completed successfully and the Raise/Scroll pushbutton is pressed, the INPUT
CALIBRATE FUNCTION screen appears and signals that calibration is complete.
175 OHM TO 0-P
PRESS LOWER KEY
200 OHM TO 0-P
PRESS LOWER KEY
225 OHM TO 0-P
PRESS LOWER KEY
