Troubleshooting and fault correction
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
103
of 142
9
4138 Invalid value at set value parameter No. 11 adjustable Check the set values in relation to the permitted
value range
4139 Invalid value at set value parameter No. 12 adjustable
4140 Invalid value at set value parameter No. 13 adjustable
4141 Invalid value at set value parameter No. 14 adjustable
4142 Invalid value at set value parameter No. 15 adjustable
4143 Invalid value at set value parameter No. 16 adjustable
4144 Invalid value for set value period adjustable
4145 Invalid value for actual value period adjustable
4146 Incorrect value for cycle offset set values adjustable
4147 Incorrect value for cycle offset actual values adjustable
4148 BACI timeout at cyclic data adjustable Check communication rate and set timeout P0839
4149 BACI timeout at service data adjustable
4150 Check results in faulty checksum IS Restart by switching off and on
4151 Ramp-up timeout when waiting for the slave type or
when waiting for the resetting of config pending flag
adjustable
4152 Invalid data transfer structure type adjustable Contact Baumüller Nürnberg GmbH
4153 Internal error: Incorrect BACI status adjustable
4154 Access conflicts with slave at cyclic communication adjustable
4155 Error cyclic communication: Parameter value wrong adjustable Check the value of the transmitted parameter
4156 Error cyclic communication: Alive counter conflict adjustable Check if option module and controller are synchro-
nous
4157 Cmd interface: Channel number wrong (0 or > 6) adjustable Contact Baumüller Nürnberg GmbH
4158 Cmd interface: Selected channel not available adjustable
4159 Cmd interface: Internal error - wrong pointer adjustable
4160 Cmd interface: Internal error - wrong state adjustable
4161 Cmd interface: Wrong package No. adjustable
4162 Cmd interface: Wrong command No. adjustable
4163 Cmd interface: Wrong state at package handling adjustable
4164 Cmd interface: Timeout at command processing adjustable
4165 Cmd interface: Wrong package length adjustable
4166 Cmd interface: Descriptor not available adjustable
4167 Cmd interface: Wrong package type adjustable
4168 Cmd interface: Checksum error adjustable
4169 Module identification: PCI error at reading adjustable Check option module for correct operation
4170 Module identification: PCI error at writing adjustable
4171 Module identification: General error at reading adjustable
4172 Module identification: General error at writing adjustable
4173 Internal error adjustable Contact Baumüller Nürnberg GmbH
4174 Configuration cyclic services: Parameters are not
cyclic writable
adjustable Select another parameter
4175 Configuration cyclic services: Invalid parameter No. adjustable
4176 Wrong option module error code adjustable Contact Baumüller Nürnberg GmbH
4177 to 8192 reserved
Error code Meaning Reaction Troubleshooting
