Technical Data
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
25
of 142
3
*: min. expansion space, also consider ZCooling– on page 29
**: width inclusively bolt heads
Figure 6: Installation space BM4163-S/Z
3.2 Weight
Device Dimensions
(B x H x T)
Weight with controller,
without plug-in module
BM4135 155 x 540 x 340 mm 16,4 kg
BM4145 190 x 665 x 374 mm 26,1 kg
BM4163 437 x 920 x 380 mm 68,5 kg
