Baumuller b maXX 4100 Series User Manual

Accessories and Spare Parts
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
125
of 142
11
11.7.3 Design cover and connectors
BM4135 BM4145 BM4463 Part No.
Design cover (yellow) narrow X X X 351209
Connector X11
Phönix: GMSTB 2,5HCV/6-ST-
7,62
1714317
X X X 409624
Connector X3
Phönix: FK-MCP 1,5/6-ST-3,81 1851083
X X X 354874
Connector X100
Wieland: 8513 BFK, 25.630.3653.0
X X X 354810
Connector A: X1
Phönix: GMSTB 2,5HCV/4-ST-
7,62
1714294
X X X 409625
Connector B: X1, C: X1 for version 01
Phönix: FRONT-GMSTB 2,5/3-ST-
7,62
1806122
X X X 385623
Connector B: X1, C: X1 vor version 02
Phönix: FRONT-GMSTB 2,5/2-ST-
7,62
1766990
X X X 396131
Connector D: X1
Wieland: 8513 BFK, 25.630.4053.0
X X X 354815
