Error handling
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
96
of 142
9.4
9.4.2.1 Error messages (2nd level)
In the column ’Reaction’ the reaction of the system to the error is shown:
m „IS“ = pulse inhibit;
m „adjustable“ = the error reaction can be set via ProDrive (Window „Drive management“,
toolbar button „Error reaction“).
m „no reaction’ means, the drive is continuing to work and the red error LED is blinking.
P0201 Error processor
P0202 Error operating system
Error No. Meaning Reaction Troubleshooting
0 reserved
1 Watchdog error IS Restart BM4100 (NWR)
2 Incorrect or unexpected interrupt has occurred IS
3 NMI Interrupt / bus error IS
4 to 15 reserved, not assigned = 0
Error No. Meaning Reaction Troubleshooting
16 Boot error IS Restart BM4100 (NWR)
17 Software error IS
18 Time slot configuration IS
19 Time slot - time error IS Restart BM4100 (NWR);
Change configuration of the time slice operation sys-
tem
20 1 = no free memory IS Restart BM4100 (NWR)
21 Invalid error code IS
22 invalid warning code IS
23 incorrect FPGA version IS Contact Baumüller Nürnberg GmbH
24 to 31 reserved, not assigned = 0
