Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
3TECHNICAL DATA
3.1 Dimensions
The following dimension drawings show the main dimensions of the devices. By means
of the dimension drawings the space requirements within the control cabinet are deter
-
mined. The dimension drawings in ZDrilling patterns– from page 53 must be used in or-
der to do the required drilling / segments.
NOTE!
All dimensions in mm.
