Electrical data
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
30
of 142
3.4
3.4 Electrical data
3.4.1 Electrical data - BM4135
1)
All rated values refer to a mains input voltage of 400 V / 50 Hz and a control voltage of 24 V.
2)
Effective value at an environmental temperature of 40 °C.
3)
Between 40 °C and 55 °C the output current must be reduced.
The permitted output current (I
0
) is calculated with the following formula:
BM4135
Input rated power
1)
38 kVA
Input rated current (I
eff
)
1) 2) 3) 4)
55 A
Input peak current (I
eff
)
1) 2) 4) 5)
82,5 A
PWM switching frequency 8 kHz
DC link voltage 640 V
DC
to 760 V
DC
DC link capacity (internal) 2000 µF
DC link discharging time (internal DC link capacity) 430 s
DC link capacity (external), permitted max. 18 mF
Output power DC link
1) 6)
max. 35 kW
Peak power DC link
7)
52 kW
Max. peak power time
5)
60 s
Power factor (only inductive) 0,9 to 1,0
Switch-on frequency v 2 min,
see ZPower on switching frequency–
from page 83
Max. charging time b 30 s
Fast discharge b 5 s
Chopper current, permitted (Î) max. 50,0 A
Chopper resistor external ≥ 16 Ω
Chopper on voltage (Û) 814 V
Chopper peak power 40 kW
Permitted chopper continuos power 10 kW
Power loss related to mains connection
8)
1020 W
Power loss related to control voltage max. 88 W
I
0
I
040°C()
1
Coolant temperature - 40 °C
°C
----------------------------------------------------------------------------- -
003,⋅


–


⋅=
