Monitoring
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
84
of 142
8.5
8.5 Monitoring
The controller unit monitors the device during the operation. If the controller unit recog-
nizes a status, which deviates from normal operation, the device either issues a warning
or an error message.
Warning If the controller unit recognizes an operating condition, which is close to an error condi-
tion, an accordant warning message is shown in ProDrive and by the control respectively.
The most important warning (current limit reached) the device also shows via the LED H3
(see
ZCurrent limit (H3)– on page 44).
Error message The controller unit recognizes, that the device is not error-free, this is shown via the LED
H4 (see
ZError (H4)– on page 44) and via the 7-segment-display. Furthermore an ac-
cording error text is shown from ProDrive or the control can read out an error code from
the device.
Further information is to be found in chapter (ZTroubleshooting and fault correction– from
page 85).
