Troubleshooting and fault correction
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
95
of 142
9
9.4.2 Error parameters, error messages, error reactions
Figure 43: Structure of the error list - survey
1st level 1st level errors are only interesting for the access to errors via parameters, to be used
without ProDrive, e. g. at Field bus communication. This errors are not shown in ProDrive/
7-segment display.
Bit mapping see description of the parameter P0200 in the parameter manual.
2nd level
3rd level
Order of the error messages see survey (ZFigure 43on page 95).
2nd level error messages are displayed on the 7-segment display in ProDrive.
LEVEL 1 LEVEL 2 LEVEL 3
SysError 1 ProcessorError
OperationError
ProprogError
ExtendedModuleError
PSU_Error
AmpError
DriveManagError
DataRecError
CANSyncError
FunctionModule_A
FunctionModule_B
FunctionModule_C
FunctionModule_D
FunctionModule_E
OptionModule_G
OptionModul_H
