Connection diagram with SEA-01 / SRM-01
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
66
of 142
7.12
7.12 Connection diagram with SEA-01 / SRM-01
c
Charge circuit
d
Power supply unregulated 24 V ± 10 % with secure electrical separation (PELV) accordant EN 50178
e
DC link voltage monitoring
f
Chopper resistor control
g
Chopper resistor ON
h
Chopper resistor bus
i
Mains voltage monitoring
j
Pulse enable
k
Reset error memory
cb
Ready for pulse enable
cc
Power limit reached
cd
Ready-for-operate drive
(additional signal for compatibility with former devices), either signal cb or signal cd can be used
(we recommend signal cb)
ce
Main contactor ON
cf
Monitoring signal main contactor
cg
Fan for power unit (only for BM4145 upwards)
ch
Ready for main contactor ON
ci
Mains filter, see ZMains filters– on page 118
BFO
Surge protections module, see ZSurge protection module– on page 118
BA-...1D1
see ZFigure 29– on page 71 and the following
L / N (X36)
Connections for fan (only from BM4145 upwards)
1U1, 1V1, 1W1
see ZFigure 29– on page 71 and the following
D1
HF mains choke
F1, F2, F3, F7
Fuse, see ZFuses– on page 116
LS
Charging contactor
HS
Main contactor
X11
see ZFigure 29– on page 71 and the following.
X100
see ZFigure 32– on page 74
A:X1
see ZFigure 34– on page 76
B:X1
see ZFigure 34– on page 76
C:X1
see ZFigure 34– on page 76
D:X1
see ZFigure 34– on page 76
