Type code
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
42
of 142
4.5
4.5 Type code
The type key has the form: BM4XXX - XXX - XXXXX - XX. Directly behind the type key is
the design code (- XXXX - XXXX). The design code contains information, which only is
important to Baumüller Nürnberg GmbH. That’s why in the following table only the type
key is explained.
BM4XXX - XXX - XXXXX - XX Device generation
BM4XXX - XXX - XXXXX - XX Controller type
1: Vector controller for mains converter
BM4XXX - XXX - XXXXX - XX Size of cabinet
3 to 6
BM4XXX - XXX - XXXXX - XX Current grading (output rated current)
BM4XXX - XXX - XXXXX - XX Cooling type
S: air-cooled with air supply and with air outlet in the control cabinet
BM4XXX - XXX - XXXXX - XX Mains type
T: TN- or TT-mains
BM4XXX - XXX - XXXXX - XX Safety relay
0: no module
BM4XXX - XXX - XXXXX - XX Hardware type
XXXXX: Power unit construction
XXXXX: Controller unit variants
X0XXX: Modules in slots A to E pluggable
X1XXX: Modules in slots A to H pluggable
XXXXX: internal information via Baumüller Nürnberg GmbH.
BM4XXX - XXX - XXXXX - XX State of software controller (hardware)
03: Series version 3.x
NOTE
This type key is only for the basic device without the plug-in modules. Every plug-in
module (except the controller) has its own type key.
