Baumuller b maXX 4100 Series User Manual

Design and Operation
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
43
of 142
4
4.6 Marking of the function modules - type key
On the front sheet you will find the type key of the plug-in module.
4.7 UL notes
m ZRequirements to the connecting cables– on page 62
n Use 60 °C/75 °C copper wire only for all devices
n Use Class 1 wire only.
m ZConnection diagrams– from page 71
n Note tightening torque for connection terminals.
m ZRequired environmental conditions– on page 28
n Use the device only in a pollution degree 2 environment
n Observe the maximum environmental temperature and the derating
m ZRequirements to the energy supply / supply system– on page 27
n For use on a solidly grounded wye source only
n The control circuit shall be supplied by an isolated power supply or control trans-
former rated max. 42.4 V peak, 10,000 VA.
m ZFuses– from page 116
n BM4135 may also be protected with Type E self protected combination motor con-
troller, sized based on the rated current
n Converters may be used with listed fuses or listed circuit breakers DIVQ as overcur-
rent protection.
cUL notes Additional only for Canada:
NOTE
This type key is valid only for permanently installed function modules of the series b
maXX 4100. Other plug-in modules have an own type key.
BM4 - F - XXX - XX Device family, in which the plug-in module can be build in
BM4 - F - XXX - XX Plug-in module type (function module)
BM4 - F - XXX - XX Plug-in module identification
SEA:
SRM:
UME:
DIO:
Main contactor control module
Main contactor monitoring module
Mains voltage sensing module
Digital I/O module
NOTE
Overvoltage Protection Device have to be installed in front of the input circuit of the
device to limit the maximum overvoltage peak to 2.5
kV.
